the casting machine
the casting machine is also provided with the following characteristics:
it has two operating modes: cab operation and remote control outside the cab. casting is first controlled by the steering wheel and first-time remote control is realized. it is suitable for operation of the ladle pouring worker and is user-friendly. the operation is simple and easy to master, with low technical requirements for the operators. it is a breakthrough among other original pouring machines.
simple and useful structure,easy maintenance.
special position of the rotating shaft, and smooth pouring.
high safety level. it has a safety voltage supply system, which effectively protects the casting machine from being influenced by the harmonic wave in power network, isolates the pollution of power network by variable-frequency operation of the casting machine, and guarantees better stability of the casting machine. in addition, it can prevent electric shock.
multiple presetting, consolidation and storage of flow parameter of the stream inoculation device. quick parameter adjustment may be achieved by means of manual or remote control according to the pouring flow rate.
the equipment has been widely recognized and praised by the users after large-scale mass production test during practical production, providing a strong guarantee for the foundry enterprises to achieve automatic and safe pouring.
the casting machine has obtained many patents,patent number: 201220255147.1 and so on
main parameters of a standard casting machine
name | parameters | name | parameters |
casting ladle rated capacity | 1-2t | casting machine move speed | 0-20m/min |
move distance
| based on casting need | casting cart move speed | 0-0.1m/s |
casting cart maximum distance | 600mm | maximum casting converting angle | 75° |
casting converting speed | 0-6°/s | ladle back converting speed | 0-8°/s |
casting indenter | 200mm | remote control distance | 0-100m |
total power | 10kw | total weight | -5t |
mainframe dimensions |
4200×1800×3600mm
| ||
